0.5x1000 mm N-BK7 Biconvex Lens

Product description

The biconvex lens made from N-BK7 material is ideal for applications in medical and microscopy fields. With focal lengths ranging from 1000 mm to 3000 mm and diameters between 0.5 mm and 5.0 mm, this lens provides versatility for various optical setups. Its surface quality of 60/40 ensures reliable performance, while optional anti-reflective coatings enhance transmittance. Custom sizes and OEM/ODM support are available, making it suitable for tailored solutions in research and development.

Key Features

Focal lengths of 1000 mm to 3000 mm for diverse application needs.
Diameter options from 0.5 mm to 5.0 mm for flexibility in design.
Surface quality of 60/40 for reliable optical performance.
Customizable dimensions and coatings to meet specific requirements.
OEM, ODM, and OBM support for tailored manufacturing solutions.

Available Sizes

Diameter x Focal Length (mm)
2.8 x 2000

Applications

Medical, Microscopy

Specification Summary

Item	Value
Material	N-BK7
Shape	Biconvex
Diameter	0.5 mm
Focal Length	1000 mm
Surface Quality	60/40
Coating	uncoated, anti-reflective (AR)

Full Specifications

Parameter	Value
Type	Convex Lens
Customized Support	OEM, ODM, OBM
Warranty	3 Years
Weight	0.03
Diameter Tolerance	+/-0.1
Surface Flatness	1/4@633nm
Clear Aperture	>=central 80% of diameter

FAQ

Can I get custom sizes for this lens?

Yes, custom sizes are available, with diameter options from 0.5 mm to 5.0 mm.

What is the minimum order quantity (MOQ)?

The MOQ is not specified, allowing for flexible procurement options.
