3 mm N-BK7 Lens
N-BK7 optical component for 1.7-3 μm and 3-5 μm applications, customizable with precise tolerances.
Core attributes
- Material
- N-BK7
- Diameter
- 3 mm
- Surface Quality
- 60/40
- Transmission bands
- MWIR (3-5 μm), SWIR (1.7-3 μm)
Product facts
Key attributes
- Material
- N-BK7
- Diameter
- 3 mm
- Surface Quality
- 60/40
- Transmission bands
- MWIR (3-5 μm), SWIR (1.7-3 μm)
Product description
This N-BK7 optical component is designed for applications in the 1.7-3 μm and 3-5 μm wavelength bands, making it suitable for IR imaging, LIDAR, and medical devices. With a diameter of 3.0 mm, it offers a surface quality of 60/40, ensuring reliable performance in demanding environments. This component is ideal for R&D and production needs, providing consistent quality and support for custom sizing.
Key Features
- Diameter of 3.0 mm for compact integration in various systems.
- Surface quality of 60/40 for reliable optical performance.
- Customized support available for tailored solutions.
- Dimension tolerance of ±0.01 mm for precision applications.
- ISO9001 certification ensures consistent manufacturing quality.
Specification Summary
| Item | Value |
|---|---|
| Material | N-BK7 |
| Diameter | 3 mm |
| Surface Quality | 60/40 |
| Transmission bands | MWIR (3-5 μm), SWIR (1.7-3 μm) |
Full Specifications
| Parameter | Value |
|---|---|
| Customized Support | OEM |
| Warranty | 3 Years |
| Weight | 0.05kg(0.11lb) |
| Dimension Tolerance | ±0.01mm |
| Thickness Tolerance | ±0.01mm |
| Size Tolerance | 0.1mm/+0mm |
| Certification | ISO9001 |
FAQ
Is custom sizing available?
Yes, custom sizes can be accommodated within a diameter range of 1 mm to 300 mm.
What are the tolerances for this lens?
The dimension tolerance is ±0.01 mm, with a thickness tolerance of ±0.01 mm.
