1 mm N-BK7 Meniscus Lens, AR Coated

Product description

The N-BK7 meniscus lens is designed for projection applications, effectively collecting and focusing light. With a diameter of 1 mm and a weight of only 0.05 kg, this lens is suitable for compact optical systems. Its double convex structure and AR coatings enhance optical performance, making it ideal for applications requiring precise light manipulation. Sourced from Jiangsu, this lens offers customization options to fit specific project needs.

Key Features

Diameter of 1 mm ensures compatibility with compact systems.
AR coatings improve light transmission and reduce reflections.
Flatness of 1/4 lambda enhances image quality.
Diameter tolerance of +0.0-0.1 mm ensures precise fitting.
Customizable support available for OEM projects.

Applications

Projection

Specification Summary

Item	Value
Material	N-BK7
Shape	Meniscus
Diameter	1 mm
Coating	anti-reflective (AR)

Full Specifications

Parameter	Value
Customized Support	OEM
Warranty	1 year
Weight	0.05kg(0.11lb)
Diameter Tolerance	+0.0-0.1mm
Thickness Tolerance	± 0.040 mm
Flatness	1/4lambda
Keywords	optical glass
Use	Optical
Structure	Double Convex

FAQ

Can I get custom sizes for this lens?

Yes, custom sizes are available depending on customer specifications.

What are the tolerances for diameter and thickness?

Diameter tolerance is +0.0-0.1 mm, and thickness tolerance is ±0.040 mm.
