0.5 mm N-BK7 Optical Window

Product description

This N-BK7 optical window is designed for diverse applications across multiple wavelength bands, including 0.7-1.7 μm and 3-5 μm. Its robust material and customizable options make it suitable for IR imaging, LIDAR, and laser applications. With a diameter of 0.5 mm and precise tolerances, this window ensures reliable performance in demanding environments. Originating from Jilin, it offers consistent quality for both prototyping and production needs.

Key Features

Diameter: 0.5 mm, ensuring compatibility with compact systems.
Diameter tolerance: 0.00/-0.10 mm for precise fitting.
Thickness tolerance: 0.1 mm ~ +/-0.02 mm for reliable performance.
Customizable support available for OEM projects.
Suitable for multiple wavelength bands: 0.7-1.7 μm, 3-5 μm, and more.

Specification Summary

Item	Value
Material	N-BK7
Diameter	0.5 mm
Thickness	Custom
Transmission bands	MWIR (3-5 μm), SWIR (1.7-3 μm), NIR (0.7-1.7 μm), VIS (400-700 nm), UV (<400 nm)
MOQ	—

Full Specifications

Parameter	Value
Type	Window
Customized Support	OEM
Weight	1
Diameter Tolerance	0.00/-0.10 Mm
Thickness Tolerance	0.1mm~+/-0.02mm

FAQ

Can I get custom sizes?

Yes, customizable support is available for OEM projects.

What are the tolerances for diameter and thickness?

Diameter tolerance is 0.00/-0.10 mm; thickness tolerance is 0.1 mm ~ +/-0.02 mm.
