5 mm N-BK7 Plano-concave Lens, AR Coated
N-BK7 plano-concave achromatic lens for precise optical alignment, customizable for various applications.
Core attributes
- Material
- N-BK7
- Shape
- Plano-concave
- Diameter
- 5 mm
- Coating
- anti-reflective (AR)
- Transmission bands
- NIR (0.7-1.7 μm), VIS (400-700 nm), UV (<400 nm)
Product facts
Key attributes
- Material
- N-BK7
- Shape
- Plano-concave
- Diameter
- 5 mm
- Coating
- anti-reflective (AR)
- Transmission bands
- NIR (0.7-1.7 μm), VIS (400-700 nm), UV (<400 nm)
Product description
The plano-concave achromatic lens made from N-BK7 material is designed for precise optical alignment across various applications, including IR imaging and laser systems. With a wavelength range of 0.7-1.7 μm, 400-700 nm, and <400 nm, it ensures high clarity and minimal distortion. The anti-reflective coating enhances light transmission, making it suitable for demanding optical environments. Customization options are available to meet specific project requirements.
Key Features
- Wavelength compatibility: Suitable for 0.7-1.7 μm, 400-700 nm, and <400 nm applications.
- High clarity: Maintains sharp images with minimal distortion.
- Customizable: OEM and ODM support for tailored solutions.
- Dimension tolerance: +/-0.1 mm for precise fitting.
- Parallelism: < 3 arcmin ensures accurate optical alignment.
Specification Summary
| Item | Value |
|---|---|
| Material | N-BK7 |
| Shape | Plano-concave |
| Diameter | 5 mm |
| Coating | anti-reflective (AR) |
| Transmission bands | NIR (0.7-1.7 μm), VIS (400-700 nm), UV (<400 nm) |
Full Specifications
| Parameter | Value |
|---|---|
| Type | Achromatic Lens |
| Customized Support | OEM, ODM |
| Warranty | 6 months |
| Weight | 0.05g(0oz) |
| Dimension Tolerance | +/-0.1mm |
| Focal Length Tolerance | ±2% |
| Parallelism | < 3 arcmin |
| Clear Aperture | >90% |
FAQ
Is custom sizing available?
Yes, OEM and ODM support allows for tailored solutions.
What is the dimension tolerance?
The dimension tolerance is +/-0.1 mm.
Product inquiry
Request a quote
Share your application and target specifications. Optional optical details help clarify the request.
