5 mm N-BK7 Plano-convex Lens, AR Coated
Explore N-BK7 plano-convex achromatic lenses for collimation and imaging in the 400-700 nm range. Custom sizes available.
Core attributes
- Material
- N-BK7
- Shape
- Plano-convex
- Diameter
- 5 mm
- Coating
- anti-reflective (AR), high-reflective (HR)
- Transmission bands
- VIS (400-700 nm)
Product facts
Key attributes
- Material
- N-BK7
- Shape
- Plano-convex
- Diameter
- 5 mm
- Coating
- anti-reflective (AR), high-reflective (HR)
- Transmission bands
- VIS (400-700 nm)
Product description
The N-BK7 plano-convex achromatic lens is designed for applications in collimation and imaging within the 400-700 nm wavelength range. By combining two lens elements, this lens minimizes chromatic aberration and enhances optical performance, making it ideal for critical imaging tasks. With a wide diameter range from 5.0 mm to 500.0 mm, this lens can be tailored to fit various optical systems, ensuring high clarity and color accuracy.
Key Features
- Diameter options from 5.0 mm to 500.0 mm for versatile application fit.
- Achromatic design reduces chromatic aberration, providing sharper images.
- Clear aperture greater than 90% ensures maximum light transmission.
- Parallelism within < 3 arcmin enhances alignment in optical setups.
- Custom support available for OEM and ODM projects.
Applications
Collimation, Imaging
Specification Summary
| Item | Value |
|---|---|
| Material | N-BK7 |
| Shape | Plano-convex |
| Diameter | 5 mm |
| Coating | anti-reflective (AR), high-reflective (HR) |
| Transmission bands | VIS (400-700 nm) |
Full Specifications
| Parameter | Value |
|---|---|
| Type | Achromatic Lens |
| Customized Support | OEM, ODM |
| Warranty | 6 months |
| Weight | 0.05g |
| Dimension Tolerance | +/-0.1mm |
| Focal Length Tolerance | ±2% |
| Parallelism | < 3 arcmin |
| Clear Aperture | >90% |
FAQ
What are the tolerances for custom sizes?
Dimension tolerance is ±0.1 mm and focal length tolerance is ±2%.
What is the minimum order quantity?
Minimum order quantity is not specified; inquire for details.
Product inquiry
Request a quote
Share your application and target specifications. Optional optical details help clarify the request.
