0.5 mm N-BK7 Round Optical Window, AR Coated
N-BK7 optical windows with customizable sizes, 60/40 surface quality, and fine polished edges for various applications.
Core attributes
- Material
- N-BK7
- Shape
- round
- Diameter range
- 0.5–50 mm
- Coating
- ar
Product facts
Key attributes
- Material
- N-BK7
- Shape
- round
- Diameter range
- 0.5–50 mm
- Coating
- ar
Product description
This optical window, made from N-BK7 glass, is designed to protect sensitive electronic sensors and detectors from environmental factors. With a diameter range from 0.5 mm to 50 mm, it offers versatility for various applications, including LIDAR and medical devices. The window features a surface quality of 60/40 and fine polished edges, ensuring clarity and durability. Its compatibility with custom coatings and sizes makes it suitable for specific project requirements.
Key Features
- Diameter range: 0.5 mm to 50 mm for diverse application needs.
- Surface quality of 60/40 ensures minimal distortion for precise optics.
- Fine polished edges enhance durability and aesthetic appeal.
- Customizable options available for OEM and ODM projects.
- Works at temperatures up to 1100°C, suitable for high-performance environments.
Specification Summary
| Item | Value |
|---|---|
| Material | N-BK7 |
| Shape | Round |
| Diameter | 0.5 mm |
| Thickness | Custom |
| Surface Quality | 60/40 |
| Coating | anti-reflective (AR) |
| MOQ | — |
Full Specifications
| Parameter | Value |
|---|---|
| Type | Convex Lens, Fresnel Lens, Aspherical Lens, Concave Lens, Achromatic Lens, Plano… |
| Customized Support | OEM, ODM |
| Warranty | 1 years |
| Weight | Customized |
| Density | 2.2g/cm3 |
| Work Temperature | 1100 Degrees Celsius |
| Edges Treatment | Fine Polished Edge |
| Thickness Tolerance | ±0.01mm |
| Package | Carton+Bubble Film+Wooden Cases |
| Parallelism | ±30 arc sec |
FAQ
What is the thickness tolerance of the optical window?
The thickness tolerance is ±0.01 mm, ensuring precision in applications.
Can I order custom sizes?
Yes, the optical window can be customized to meet specific size requirements.
