3x0.1 mm N-BK7 Round Optical Window, AR Coated

Product description

The K9L Glass Visual Port is an optical window designed for security applications, offering exceptional performance with a surface quality of 10/5. This round aspherical lens is crafted from N-BK7 material, ensuring durability and reliability in various optical settings. With a diameter of 3.0 mm and a thickness of 0.15 mm, it is suitable for integration into compact systems requiring precise optical components. Custom sizes are available to meet specific project needs.

Key Features

Diameter of 3.0 mm ensures compatibility with compact optical systems.
Thickness of 0.15 mm allows for lightweight designs without compromising performance.
Surface quality rating of 10/5 provides superior clarity and minimal distortion.
Diameter tolerance of +/-0.01 mm ensures precise fitting in assemblies.
Customizable options available for OEM and ODM projects.

Available Sizes

Diameter x Thickness (mm)
3 x 0.1

Applications

Security

Specification Summary

Item	Value
Material	N-BK7
Shape	Round
Diameter	3 mm
Thickness	0.1 mm
Surface Quality	10/5
Coating	anti-reflective (AR)
MOQ	—

Full Specifications

Parameter	Value
Type	Aspherical Lens; optical window
Customized Support	OEM, ODM
Warranty	as requested
Weight	As requested
Name	K9L Glass Visual Port
Diameter Tolerance	+/-0.01mm
Thickness Tolerance	+/-0.1mm
Surface Figure	lamda/10(PV flat surface can achieve 0.03um per 150mm)

FAQ

Can I get custom sizes?

Yes, custom sizes are available, with diameter options ranging from 3 mm to 460 mm.

What are the tolerances for diameter and thickness?

Diameter tolerance is +/-0.01 mm, and thickness tolerance is +/-0.1 mm.
