5x0.5 mm N-BK7 Step Optical Window

Product description

The N-BK7 step window is designed for precision optical applications, providing high transmittance and customizable dimensions. Ideal for use in IR imaging, LIDAR, and laser systems, this window accommodates a wide range of diameters from 5.0 mm to 300.0 mm and thicknesses from 0.5 mm to 50.0 mm, ensuring versatility for various project requirements.

Key Features

Diameter range: 5.0 mm to 300.0 mm for diverse application needs.
Thickness options: 0.5 mm to 50.0 mm for tailored solutions.
High transmittance: 90% or higher with AR coating for optimal performance.
Custom sizes available, including variants like 152.5 mm x 25.2 mm.
OEM, ODM, and OBM support for customized projects.

Available Sizes

Diameter x Thickness (mm)
152.5 x 25.2

Specification Summary

Item	Value
Material	N-BK7
Shape	Step
Diameter	5 mm
Thickness	0.5 mm
MOQ	—

Full Specifications

Parameter	Value
Type	Plano
Customized Support	OEM, ODM, OBM
Warranty	2 years
Weight	as needed
Chamfer	0.25*45 degree or as needed
Transmission	90% or higher with AR coating
Sample	sample can be provided or customize

FAQ

Can I get custom sizes?

Yes, custom sizes are available, including specific variants like 152.5 mm x 25.2 mm.

What is the minimum order quantity?

The minimum order quantity is not specified; please inquire for details.
