300 mm Optical Glass Aspheric Lens, AR Coated
Aspheric lens for collimation and imaging (400-700 nm), 300 mm diameter, customizable, with anti-reflective coating.
Core attributes
- Material
- Optical Glass
- Shape
- Aspheric
- Diameter
- 300 mm
- Thickness
- 0.1 mm
- Surface Quality
- 80/50
- Coating
- anti-reflective (AR)
- Transmission bands
- VIS (400-700 nm)
Product facts
Key attributes
- Material
- Optical Glass
- Shape
- Aspheric
- Diameter
- 300 mm
- Thickness
- 0.1 mm
- Surface Quality
- 80/50
- Coating
- anti-reflective (AR)
- Transmission bands
- VIS (400-700 nm)
Product description
This aspheric lens is engineered for applications in collimation and imaging across the 400-700 nm wavelength range. Its design minimizes spherical aberration, enhancing optical performance in systems that require precise light focusing. With a diameter of 300 mm and a thickness of 100 mm, this lens is ideal for reducing the number of components in optical assemblies, simplifying integration and improving overall system efficiency.
Key Features
- Diameter: 300 mm for versatile application fit.
- Thickness: 100 mm, ensuring robust performance.
- Surface quality: 80/50, delivering high clarity and minimal distortion.
- Anti-reflective coating enhances visibility by reducing glare.
- OEM customization available for tailored solutions.
Applications
Collimation, Imaging
Specification Summary
| Item | Value |
|---|---|
| Material | Optical Glass |
| Shape | Aspheric |
| Diameter | 300 mm |
| Thickness | 0.1 mm |
| Surface Quality | 80/50 |
| Coating | anti-reflective (AR) |
| Transmission bands | VIS (400-700 nm) |
Full Specifications
| Parameter | Value |
|---|---|
| Type | Aspheric Lenses |
| Customized Support | OEM |
| Warranty | 3 Years |
| Weight | 0.5 |
| Color | Transparent |
| Dimension Tolerance | +/-0.05mm |
FAQ
What is the diameter range for custom sizes?
Custom sizes can range from 0.5 mm to 300 mm in diameter.
What are the tolerances for dimensions?
The dimension tolerance is +/-0.05 mm.
