52x217 mm Optical Glass Biconvex Lens, AR Coated
Discover our biconvex lens for projection applications, featuring AR coatings and customizable options.
Core attributes
- Material
- Optical Glass
- Shape
- Biconvex
- Diameter
- 52 mm
- Focal Length
- 217 mm
- Surface Quality
- 60/40
- Coating
- anti-reflective (AR)
Product facts
Key attributes
- Material
- Optical Glass
- Shape
- Biconvex
- Diameter
- 52 mm
- Focal Length
- 217 mm
- Surface Quality
- 60/40
- Coating
- anti-reflective (AR)
Product description
This biconvex lens is designed for projection applications, effectively converging light to form clear images. With a diameter of 52mm and a focal length of 217mm, it is suitable for various optical setups. The lens features AR coatings for enhanced performance and a surface quality rating of 60/40, ensuring high clarity and minimal distortion. Custom sizes and OEM/ODM support are available, making it adaptable for specific project requirements.
Key Features
- Diameter: 52mm for standard compatibility in optical systems.
- Focal Length: 217mm for effective image projection.
- AR Coated to enhance transmittance and reduce reflections.
- Surface Quality: 60/40 ensures minimal optical distortion.
- Diameter Tolerance: +/-0.0-0.1mm for precise fitting.
Available Sizes
| Diameter x Focal Length (mm) |
|---|
| 52 x 217 |
| 70 x 150 |
Applications
Projection
Specification Summary
| Item | Value |
|---|---|
| Material | Optical Glass |
| Shape | Biconvex |
| Diameter | 52 mm |
| Focal Length | 217 mm |
| Surface Quality | 60/40 |
| Coating | anti-reflective (AR) |
Full Specifications
| Parameter | Value |
|---|---|
| Type | Biconvex Lens |
| Customized Support | OEM, ODM, OBM |
| Warranty | 3 Years |
| Weight | 0.05 |
| Diameter Tolerance | +/-0.0-0.1mm |
| Center Thickness | 6.8mm |
| Clear Aperture | more than 98% |
| Coated | ar coated |
| Edge Thickness | 3.7mm |
FAQ
Can I get custom sizes?
Yes, custom sizes and focal lengths are available upon request.
What is the minimum order quantity (MOQ)?
The MOQ is not specified; please inquire for details.
