1 mm Optical Glass Optical Filter

Product description

This 460nm bandpass filter is designed for applications requiring high transmission and specific wavelength selection. With a transmittance of 92%, it effectively blocks unwanted wavelengths, making it ideal for fluorescence microscopy and other optical applications. The filter’s design ensures a clear aperture greater than 90%, enhancing image quality. Its robust optical glass construction provides durability for various environments.

Key Features

Transmittance of 92% ensures high light throughput for optimal performance.
Center wavelength (CWL) of 460nm tailored for specific applications.
Customizable options available, including OEM and ODM support.
Tolerance range of +/-0.02mm to +/-0.1mm for precise fitting.
Durable optical glass construction suitable for diverse environmental conditions.

Specification Summary

Item	Value
Material	Optical Glass
Size	1 mm
Thickness	Custom
Transmittance	92%
Filter Type	bandpass
Cwl	460nm
Transmission bands	VIS (400-700 nm)

Full Specifications

Parameter	Value
Transmittance	block; 92%
Customized Support	OEM, ODM, OBM
Warranty	2 Years
Tolerance	+/-0.02mm to +/-0.1mm
Chamfer	as needed
Cwl	460nm/620nm
Fwhm	40nm
Parallelism	≤3 arc min (≤0.9 mrad)
Transmission	>92%
Clear Aperture	>90%

FAQ

Can I get custom sizes for this filter?

Yes, customizable options are available including OEM, ODM, and OBM support.

What is the tolerance for this filter?

The tolerance for this filter ranges from +/-0.02mm to +/-0.1mm.
