2 mm Optical Glass Optical Filter, AR Coated

Product description

Neutral density (ND) filters are essential for controlling light intensity in various optical applications. This optical glass ND filter offers customizable transmittance levels ranging from 60% to 99%, making it ideal for fluorescence microscopy, machine vision, and other precision optical systems. With a surface quality of 80/50 and flatness tolerances of 1 lambda to 1/10 lambda, it ensures minimal distortion and high performance in demanding environments.

Key Features

Customizable transmittance from 60% to 99% for tailored light control.
Surface quality of 80/50 ensures minimal optical distortion.
Dimension tolerance of 0.01mm for precise fitting in applications.
Flatness tolerance of 1 lambda to 1/10 lambda for optimal imaging.
Thickness tolerance of +0.00/-0.05mm for consistent performance.

Specification Summary

Item	Value
Material	Optical Glass
Size	2 mm
Thickness	Custom
Surface Quality	80/50
Filter Type	nd
Coating	anti-reflective (AR), high-reflective (HR)

Full Specifications

Parameter	Value
Transmittance	customized
Customized Support	OEM
Dimension Tolerance	0.01mm
Flatness	1 lambda to 1/10 lambda
Thickness Tolerance	+0.00/-0.05mm
Transmission	60% to 99%

FAQ

Can I get custom sizes for this filter?

Yes, the filter can be customized to meet specific size requirements.

What is the minimum order quantity (MOQ)?

The minimum order quantity is not specified, allowing for flexibility in ordering.
