Custom Size Optical Glass Optical Filter

Product description

This optical filter is designed for medical applications, providing a center wavelength of 310nm with a transmittance of 60%. It effectively blocks wavelengths outside the range of 200-1200nm, making it ideal for fluorescence microscopy and related technologies. The hard-coat finish ensures durability, enhancing performance in demanding environments.

Key Features

Transmittance of 60% ensures effective light passage for optimal imaging.
Center wavelength (CWL) at 310nm tailored for specific medical applications.
Cut-off wavelength range from 200-1200nm provides excellent blocking capabilities.
Hard-coat coating enhances environmental durability and longevity.
Customized support available for OEM and ODM projects.

Applications

Medical

Specification Summary

Item	Value
Material	Optical Glass
Size	Custom
Thickness	Custom
Surface Quality	60/40
Transmittance	60%
Cwl	310nm
Coating	hard-coat

Full Specifications

Parameter	Value
Transmittance	60%; T>60%
Customized Support	OEM, ODM
Warranty	1 year
Cwl	310nm
Fwhm	10nm
Cut Off Wavelength	200-1200nm

FAQ

Can I get custom sizes?

Custom sizes are supported through OEM and ODM options.

What is the minimum order quantity (MOQ)?

The minimum order quantity is not specified; please inquire for details.
