Custom Size Optical Glass Optical Filter

High-performance bandpass filter with 90% transmittance at 750 nm, ideal for fluorescence microscopy and optical applications.

Core attributes

Material: Optical Glass
Size: Custom
Thickness: Custom
Transmittance: 90%
Filter Type: bandpass
Cwl: 750nm
Coating: hard-coat, iad-pvd
Transmission bands: NIR (0.7-1.7 μm), VIS (400-700 nm), UV (<400 nm)

Product description

This bandpass filter is designed to enhance fluorescence microscopy and other optical applications by allowing specific wavelengths to pass while blocking unwanted light. With a center wavelength of 750 nm and a high transmittance of 90%, it effectively isolates the desired spectral range for optimal imaging. The filter is suitable for use with light sources operating between 300 and 850 nm, making it versatile for various applications in life sciences and machine vision.

Key Features

Center wavelength at 750 nm for precise spectral isolation.
High transmittance of 90% ensures maximum light throughput.
IAD hard coating for enhanced durability and environmental resistance.
Customizable options available for OEM and ODM needs.
Compatible with a wavelength range of 300~850 nm.

Specification Summary

Item	Value
Material	Optical Glass
Size	Custom
Thickness	Custom
Transmittance	90%
Filter Type	bandpass
Cwl	750nm
Coating	hard-coat, iad-pvd
Transmission bands	NIR (0.7-1.7 μm), VIS (400-700 nm), UV (<400 nm)

Full Specifications

Parameter	Value
Transmittance	/; 90%
Customized Support	OEM, ODM
Process	IAD Hard Coating
Wavelength Range	300~850nm
Fwhm	8nm or 10nm

FAQ

Can I get custom sizes?

Yes, customizable options for sizes and thicknesses are available.

What is the minimum order quantity?

The minimum order quantity is not specified, allowing for flexibility in ordering.
