Custom Size Optical Glass Optical Filter

Product description

This bandpass filter is designed for applications in laser and medical fields, effectively transmitting light within the 400-700 nm range with a center wavelength of 450 nm. With a high transmittance of 90% and strong blocking capabilities (OD > 2) outside the specified range, this filter ensures optimal performance for fluorescence microscopy and other precision applications. The hard-coat finish enhances durability and environmental resistance, making it suitable for demanding conditions.

Key Features

High transmittance of 90% ensures maximum light throughput.
Center wavelength at 450 nm tailored for laser and medical applications.
Optical density greater than 2 for effective blocking of unwanted wavelengths.
Hard-coat coating provides enhanced durability and resistance to environmental factors.
Customizable options available through OEM and ODM support.

Applications

Laser, Medical

Specification Summary

Item	Value
Material	Optical Glass
Size	Custom
Thickness	Custom
Surface Quality	60/40
Transmittance	90%
Filter Type	bandpass
Cwl	450nm
Coating	hard-coat
Transmission bands	VIS (400-700 nm)

Full Specifications

Parameter	Value
Transmittance	90%
Customized Support	OEM, ODM
Warranty	1 year
Cwl	450nm
Fwhm	25nm
Cut Off Wavelength	350-1000nm
Optical Density	OD>2

FAQ

Can I get custom sizes for this filter?

Custom sizes and thicknesses are supported through OEM and ODM options.

What is the minimum order quantity (MOQ)?

The minimum order quantity is not specified, allowing for flexible procurement.
