Custom Size Optical Glass Rectangle Optical Filter
Dichroic filter for fluorescence applications with >90% transmittance and durable hard coating. Custom sizes available.
Core attributes
- Material
- Optical Glass
- Shape
- Rectangle
- Size
- Custom
- Thickness
- Custom
- Transmittance
- 90%
- Filter Type
- dichroic
- Cwl
- 546nm
- Coating
- hard-coat, iad-pvd
- Transmission bands
- NIR (0.7-1.7 μm), VIS (400-700 nm), UV (<400 nm)
Product facts
Key attributes
- Material
- Optical Glass
- Shape
- Rectangle
- Size
- Custom
- Thickness
- Custom
- Transmittance
- 90%
- Filter Type
- dichroic
- Cwl
- 546nm
- Coating
- hard-coat, iad-pvd
- Transmission bands
- NIR (0.7-1.7 μm), VIS (400-700 nm), UV (<400 nm)
Product description
The BD-Optic dichroic filter is designed for fluorescence applications, providing precise wavelength selection for optimal performance in clinical and veterinary analyzers. With a center wavelength of 546 nm and a transmittance of over 90%, this filter efficiently separates excitation light from emitted fluorescence. Its hard-coated optical glass construction ensures durability and reliability across various environments, making it suitable for demanding laboratory settings.
Key Features
- Transmittance >90% for enhanced signal clarity.
- Dichroic filter type for effective wavelength separation.
- Wavelength range of 300~850 nm for versatile applications.
- IAD hard coating for improved environmental durability.
- Customizable support available for OEM and ODM projects.
Applications
Fluorescence
Specification Summary
| Item | Value |
|---|---|
| Material | Optical Glass |
| Shape | Rectangle |
| Size | Custom |
| Thickness | Custom |
| Transmittance | 90% |
| Filter Type | dichroic |
| Cwl | 546nm |
| Coating | hard-coat, iad-pvd |
| Transmission bands | NIR (0.7-1.7 μm), VIS (400-700 nm), UV (<400 nm) |
Full Specifications
| Parameter | Value |
|---|---|
| Transmittance | /; >90% |
| Customized Support | OEM, ODM |
| Process | IAD Hard Coating |
| Wavelength Range | 300~850nm |
| Fwhm | 8nm or 10nm |
FAQ
Can I get custom sizes?
Custom sizes are available for OEM and ODM projects.
What is the minimum order quantity?
The minimum order quantity is not specified; please inquire for details.
