0.5x0.1 mm Sapphire Optical Window

Product description

Sapphire optical components are essential for applications in semiconductor and medical fields, offering high durability and excellent transmittance across multiple wavelength bands (400 nm to 5 μm). With a thickness range of 0.1 to 350 mm and diameters from 0.5 to 750 mm, these components meet diverse requirements. Their high purity (99.9999%) and superior hardness (Mohs 9) ensure reliability in demanding environments, making them a preferred choice for R&D and procurement engineers.

Key Features

High transmittance of approximately 80% from 0.3 to 5 μm enhances optical performance.
Available in diameters from 0.5 mm to 750 mm, accommodating various application needs.
Custom sizes and OEM/ODM support enable tailored solutions for specific projects.
Superior hardness (Mohs 9) ensures durability and longevity in harsh conditions.
Roughness of Ra<0.3 nm provides excellent surface quality for precision applications.

Available Sizes

Diameter x Thickness (mm)
375.2 x 175.1

Applications

Semiconductor, Medical

Specification Summary

Item	Value
Material	Sapphire
Diameter	0.5 mm
Thickness	0.1 mm
Transmission bands	MWIR (3-5 μm), SWIR (1.7-3 μm), NIR (0.7-1.7 μm), VIS (400-700 nm), UV (<400 nm)
MOQ	—

Full Specifications

Parameter	Value
Warranty	1 Year
Customized Support	OEM, ODM
Power	400
Length	0.1-700mm
Roughness	Ra<0.3nm
S/D	10/5,40/20,60/40, 80/50

FAQ

What custom sizes can be ordered?

Custom sizes are available, with a thickness range of 0.1 to 350 mm and diameters from 0.5 mm to 750 mm.

What is the minimum order quantity (MOQ)?

The minimum order quantity is not specified, allowing flexibility in ordering.
