1.5x1 mm Sapphire Optical Window, AR Coated

Product description

Sapphire windows provide exceptional durability and optical clarity for demanding applications, including IR imaging and LIDAR systems. With a broad diameter range of 1.5 mm to 250 mm and thickness options from 1.0 mm to 50.0 mm, these windows are designed to meet various specifications. The 60/40 surface quality ensures minimal distortion, while anti-reflective coatings enhance transmittance, making them ideal for high-performance environments.

Key Features

Diameter range: 1.5 mm to 250 mm for versatile application fit.
Thickness options from 1.0 mm to 50.0 mm accommodate different design needs.
Surface quality of 60/40 minimizes optical distortion, enhancing image clarity.
Customizable through OEM support to meet specific project requirements.
Diameter tolerance of ±0.1 mm ensures precise fit in assemblies.

Available Sizes

Diameter x Thickness (mm)
125.8 x 25.5

Specification Summary

Item	Value
Material	Sapphire
Diameter	1.5 mm
Thickness	1 mm
Surface Quality	60/40
Coating	anti-reflective (AR)
MOQ	—

Full Specifications

Parameter	Value
Type	Flat glass
Customized Support	OEM
Warranty	3 months
Weight	0.05kg(0.11lb)
Diameter Tolerance	±0.1mm
Thickness Tolerance	±0.1mm
Parallelism	<10 arc min
Clear Aperture	>95%

FAQ

Can I get custom sizes?

Yes, sapphire windows are customizable, and OEM support is available for specific dimensions.

What are the tolerances for diameter and thickness?

Diameter tolerance is ±0.1 mm, and thickness tolerance is also ±0.1 mm.
