1 / 6Optical Windows
10x0.5 mm Sapphire Optical Window, AR Coated
Sapphire achromatic lens for semiconductor and medical applications. Custom sizes, high transmittance, and OEM support available.
Core attributes
- Material
- Sapphire
- Diameter range
- 10 mm
- Thickness
- 0.5–100 mm
- Coating
- ar
Product facts
Key attributes
- Material
- Sapphire
- Diameter range
- 10 mm
- Thickness
- 0.5–100 mm
- Coating
- ar
Product description
This sapphire achromatic lens is designed for applications in semiconductor and medical fields, providing excellent transmittance across multiple wavelength bands including 0.7-1.7 μm and 3-5 μm. With a thickness range from 0.5 mm to 100 mm and a standard diameter of 10 mm, it meets diverse optical requirements. The lens features anti-reflective coatings to enhance performance, making it suitable for high-precision applications. Sourced from Hubei, this product benefits from 16 years of manufacturing expertise.
Key Features
- Transmittance of approximately 80% from 0.3-5 μm for enhanced optical clarity.
- Custom sizes available, including diameters from 10 mm to 50.2 mm, to fit specific application needs.
- Durable sapphire material with a Mohs hardness of 9, ensuring longevity in demanding environments.
- OEM, ODM, and OBM support for tailored solutions to meet unique project specifications.
- Roughness of Ra≤0.5 nm for superior surface quality and performance.
Available Sizes
| Diameter x Thickness (mm) |
|---|
| 10 x 50.2 |
Applications
Semiconductor, Medical
Specification Summary
| Item | Value |
|---|---|
| Material | Sapphire |
| Diameter | 10 mm |
| Thickness | 0.5 mm |
| Coating | anti-reflective (AR) |
| Transmission bands | MWIR (3-5 μm), SWIR (1.7-3 μm), NIR (0.7-1.7 μm), VIS (400-700 nm), UV (<400 nm) |
| MOQ | — |
Full Specifications
| Parameter | Value |
|---|---|
| Type | Achromatic Lens |
| Customized Support | OEM, ODM, OBM |
| Warranty | 1 Year |
| Weight | 2000g |
| S/D | 80/50, 60/40, 40/20, 20/10 |
| Roughness | Ra≤0.5nm |
FAQ
Is custom sizing available?
Yes, custom sizes are available with diameters ranging from 10 mm to 50.2 mm.
What is the minimum order quantity (MOQ)?
The MOQ is not specified; please inquire for details on order requirements.
