1x0.5 mm Sapphire Optical Window, AR Coated

Product description

Sapphire optical components offer exceptional durability and chemical resistance, making them ideal for applications in IR laser systems and other high-performance optical setups. With transparency ranging from UV to IR (150 nm - 4.5 µm), these components are suitable for various wavelengths, including 3-5 μm and 0.7-1.7 μm. Available in diameters from 1.0 mm to 400.0 mm and thicknesses from 0.5 mm to 50.0 mm, they can be tailored to meet specific application requirements.

Key Features

High durability: Sapphire’s exceptional hardness allows for thinner optics without compromising strength.
Wide wavelength range: Suitable for applications across UV to IR wavelengths (150 nm - 4.5 µm).
Custom sizing available: Diameter options from 1.0 mm to 400.0 mm and thickness from 0.5 mm to 50.0 mm.
Low MOQ: Minimum order quantity of 100 pieces ensures accessibility for various project scales.
OEM support: Customization options available to meet specific design and performance needs.

Available Sizes

Diameter x Thickness (mm)
200.5 x 25.2

Specification Summary

Item	Value
Material	Sapphire
Diameter	1 mm
Thickness	0.5 mm
Coating	anti-reflective (AR)
Transmission bands	MWIR (3-5 μm), NIR (0.7-1.7 μm), UV (<400 nm)
MOQ	100pcs

Full Specifications

Parameter	Value
Type	Convex Lens
Customized Support	OEM
Warranty	3 months
Weight	0.01
Diameter Tolerance	+0/-0.2mm
Thickness Tolerance	+/-0.2mm
Color	Matte
Moq	100pcs

FAQ

What is the minimum order quantity?

The minimum order quantity (MOQ) is 100 pieces.

Can I get custom sizes?

Yes, custom sizes are available with diameters from 1.0 mm to 400.0 mm and thicknesses from 0.5 mm to 50.0 mm.
