1 / 6Optical Windows
124 mm Sapphire Round Optical Window, AR Coated
Round sapphire optical lens for 0.7-1.7 μm applications with AR coating, customizable sizes, and high-quality standards.
Core attributes
- Material
- Sapphire
- Shape
- round
- Diameter range
- 124 mm
- Coating
- ar
Product facts
Key attributes
- Material
- Sapphire
- Shape
- round
- Diameter range
- 124 mm
- Coating
- ar
Product description
This round sapphire optical lens is designed for applications within the 0.7-1.7 μm wavelength range, providing high transmittance and durability. Ideal for use in environments requiring precise light transmission, it features anti-reflective coatings to minimize losses. With a diameter of 124 mm and a clear aperture greater than 90%, this lens is suitable for various optical systems, ensuring reliable performance in demanding applications.
Key Features
- Diameter of 124 mm with a tolerance of +/-0.1 mm for precise fitting.
- Clear aperture greater than 90% ensures optimal light transmission.
- AR coating enhances performance in the 0.7-1.7 μm range.
- Customizable options available for OEM, ODM, and OBM projects.
- Manufactured under ISO9001 certification for quality assurance.
Specification Summary
| Item | Value |
|---|---|
| Material | Sapphire |
| Shape | Round |
| Diameter | 124 mm |
| Thickness | Custom |
| Coating | anti-reflective (AR) |
| Transmission bands | NIR (0.7-1.7 μm) |
| MOQ | — |
Full Specifications
| Parameter | Value |
|---|---|
| Type | Optical lens |
| Customized Support | OEM, ODM, OBM |
| Warranty | Available |
| Weight | 0.1 |
| Diameter Tolerance | +/-0.1mm |
| Thickness Tolerance | +0.1mm |
| Clear Aperture | >90% |
| Certification | ISO9001 |
FAQ
What is the minimum order quantity (MOQ)?
The MOQ is not specified, allowing flexibility in ordering.
Can I get custom sizes?
Yes, custom sizes and materials are available upon request.
