1x1 mm Sapphire Round Optical Window

Product description

Sapphire optical windows are designed for applications requiring high transmittance in the <400 nm wavelength range, ideal for medical devices and sensor protection. These round windows provide excellent durability and surface quality, ensuring minimal reflection and absorption, making them suitable for various optical systems. With customizable sizes and reliable performance, they meet the stringent demands of R&D and procurement engineers.

Key Features

Diameter range from 1.0 mm to 200.0 mm for versatile application fit.
Thickness options from 1.0 mm to 50.0 mm to accommodate different design requirements.
Surface quality of 60/40 ensures clarity and minimal distortion.
Clear aperture greater than 90% maximizes light transmission.
Dimension tolerance of ±0.1 mm guarantees precision in manufacturing.

Available Sizes

Diameter x Thickness (mm)
100.5 x 25.5

Applications

Medical

Specification Summary

Item	Value
Material	Sapphire
Shape	Round
Diameter	1 mm
Thickness	1 mm
Surface Quality	60/40
Transmission bands	UV (<400 nm)
MOQ	—

Full Specifications

Parameter	Value
Customized Support	OEM
Warranty	1 month
Weight	Other
Substrate	Sapphire
Dimension Tolerance	±0.1mm
Surface Flatness	L/4
Chamfer	Protective bevel as needed
Clear Aperture	>90%
Parallelism	<3 arc min
Use	For Sensor

FAQ

Can I get custom sizes for these windows?

Yes, custom sizes are available, including a variant size of 100.5 mm diameter and 25.5 mm thickness.

What are the tolerances for these optical windows?

The dimension tolerance is ±0.1 mm, ensuring high precision in the final product.
