5x1 mm Sapphire Round Optical Window, AR Coated

Product description

Sapphire windows provide exceptional performance in demanding environments, making them ideal for applications in vacuum chambers, submarine operations, and other harsh conditions. With a transmission range from 0.17 to 5.5 μm, these windows cater to a variety of wavelengths, including UV to mid-infrared. Their structural integrity allows for thinner designs compared to standard glass, ensuring reliability at high temperatures up to 2030°C. Sapphire’s high mechanical strength and chemical resistance further enhance its suitability for protective windows and viewports.

Key Features

Transmission range: 0.17 to 5.5 μm for versatile applications.
Thinner and stronger than standard glass, enhancing durability.
High pressure and vacuum resistance for demanding environments.
Customizable dimensions available with ±0.1mm tolerance.
Outstanding mechanical strength with a melting point of 2040°C.

Available Sizes

Diameter x Thickness (mm)
252.5 x 10.5

Specification Summary

Item	Value
Material	Sapphire
Shape	Round
Diameter	5 mm
Thickness	1 mm
Surface Quality	60/40
Coating	anti-reflective (AR)
Transmission bands	LWIR (8-14 μm), MWIR (3-5 μm), SWIR (1.7-3 μm), NIR (0.7-1.7 μm), VIS (400-700 nm), UV (<400 nm)
MOQ	—

Full Specifications

Parameter	Value
Type	Flat, Plano
Customized Support	OEM, ODM, OBM
Warranty	1 Year
Weight	Customization
Dimension Tolerance	±0.1mm
Flatness	1/4 Lambda @632.8nm
Parallelism	< 3 arcmin
Clear Aperture	> 90%
Bevel	0.2-0.5mmX45°

FAQ

Can I get custom sizes for sapphire windows?

Yes, sapphire windows can be customized in size, with available dimensions ranging from 5.0 mm to 500.0 mm in diameter.

What is the minimum order quantity (MOQ)?

The minimum order quantity is not specified, allowing for flexibility in orders.
