Custom Size Sapphire Round Optical Window

Product description

Sapphire optical windows provide exceptional durability and optical performance across various applications, including semiconductor and medical fields. With a wide transmission range from <400 nm to 5 μm, these windows are ideal for diverse wavelengths. Their high purity (99.9999%) and excellent thermal properties make them suitable for demanding environments, ensuring reliability in critical applications.

Key Features

Wide transmission range: <400 nm to 5 μm, suitable for multiple applications.
High purity (99.9999%) ensures minimal contamination and optimal performance.
Roughness of Ra≤0.5nm for superior surface quality and clarity.
Customizable support for OEM, ODM, and OBM projects.
Durable with a Mohs hardness of 9, ideal for harsh environments.

Applications

Semiconductor, Medical

Specification Summary

Item	Value
Material	Sapphire
Shape	Round
Diameter	Custom
Thickness	0.1 mm
Transmission bands	MWIR (3-5 μm), SWIR (1.7-3 μm), NIR (0.7-1.7 μm), VIS (400-700 nm), UV (<400 nm)
MOQ	—

Full Specifications

Parameter	Value
Warranty	2 Years
Customized Support	OEM, ODM, OBM
S/D	80/50, 60/40, 40/20, 20/10
Roughness	Ra≤0.5nm

FAQ

Can I get custom sizes for sapphire windows?

Yes, sapphire optical windows can be customized to meet specific size requirements.

What is the minimum order quantity (MOQ)?

The minimum order quantity (MOQ) is not specified, allowing for flexible purchasing.
