Custom Size Sapphire Round Optical Window

Product description

This sapphire optical window addresses critical needs in the semiconductor and medical fields, offering high durability and thermal stability across multiple wavelength bands, including 0.7-1.7 μm and 3-5 μm. With a Mohs hardness of 9 and excellent thermal conductivity, these windows are ideal for demanding applications requiring reliable performance and longevity.

Key Features

High purity (99.9999%) ensures minimal contamination for sensitive applications.
Wide thickness range (0.5 mm to 700 mm) allows for versatile application in various systems.
Roughness of Ra≤0.5 nm provides superior surface quality for optimal light transmission.
Customizable options available, including OEM and ODM services for tailored solutions.
Durable sapphire material with a melting point of 2045°C ensures longevity in harsh environments.

Applications

Semiconductor, Medical

Specification Summary

Item	Value
Material	Sapphire
Shape	Round
Diameter	Custom
Thickness	0.5 mm
Transmission bands	MWIR (3-5 μm), SWIR (1.7-3 μm), NIR (0.7-1.7 μm), VIS (400-700 nm), UV (<400 nm)
MOQ	—

Full Specifications

Parameter	Value
Warranty	2 Years
Customized Support	OEM, ODM, OBM
S/D	80/50, 60/40, 40/20, 20/10
Roughness	Ra≤0.5nm

FAQ

Can I get custom sizes?

Yes, the sapphire optical windows can be customized to meet specific size requirements.

What is the minimum order quantity?

The minimum order quantity (MOQ) is not specified, allowing for flexible purchasing options.
