2x0.5 mm Sapphire Square Optical Window, AR Coated

Product description

This optical sapphire glass window is designed for applications requiring high durability and transparency across the 400-700 nm wavelength range. With exceptional hardness (9H) and resistance to scratches, it is ideal for environments subject to high pressure, temperature, and corrosion. The sapphire material ensures excellent optical performance, making it suitable for use in advanced technologies such as space applications and high-performance optical devices.

Key Features

Wavelength Range: 400-700 nm for versatile application fit.
Thickness Range: 0.5 to 10.0 mm for various design needs.
Diameter Options: From 2.0 mm to 300.0 mm for custom applications.
Tolerance: 0.02-0.1 mm for precise fit and performance.
Customizable: Available in OEM and ODM configurations.

Available Sizes

Diameter x Thickness (mm)
151 x 5.2

Specification Summary

Item	Value
Material	Sapphire
Shape	Square
Diameter	2 mm
Thickness	0.5 mm
Coating	anti-reflective (AR)
Transmission bands	VIS (400-700 nm)
MOQ	—

Full Specifications

Parameter	Value
Type	Convex Lens, Aspherical Lens, Concave Lens, Achromatic Lens, Plano Convex Lens…
Customized Support	OEM, ODM, OBM
Warranty	2 years
Weight	as design
Chamfer	ground or beveled
Hardness	9H
Tolerance	0.02-0.1mm

FAQ

What are the available custom sizes?

Custom sizes can be provided, with diameter options ranging from 2.0 mm to 300.0 mm and thickness from 0.5 mm to 10.0 mm.

What is the tolerance for these sapphire windows?

The tolerance for these sapphire windows is between 0.02 mm and 0.1 mm, ensuring precise fitting.
