1 / 6Optical Windows
5 mm Silicon Round Optical Window, AR Coated
High-performance silicon wafers for IR optics and semiconductor applications, customizable sizes, and various coatings available.
Core attributes
- Material
- Silicon
- Shape
- round
- Diameter range
- 5–800 mm
- Coating
- ar, uncoated, dlc
Product facts
Key attributes
- Material
- Silicon
- Shape
- round
- Diameter range
- 5–800 mm
- Coating
- ar, uncoated, dlc
Product description
Silicon (Si) wafers are high-performance substrates designed for infrared optics and semiconductor applications. They excel in the 3-5 μm and 8-14 μm bands, making them ideal for thermal imaging, medical devices, and semiconductor manufacturing. With options for antireflective (AR) coatings, uncoated, or durable diamond-like carbon (DLC) coatings, these wafers provide versatility for various applications while ensuring optimal performance and reliability.
Key Features
- Broad infrared transmission range of 3-5 μm and 8-14 μm for versatile applications.
- Available in diameters from 5.0 mm to 800.0 mm for custom fit.
- Flatness specifications of 2 Lambda - Lambda/20 @632.8nm for high precision.
- Clear aperture ≥90% ensures maximum light transmission.
- Customized support for OEM, ODM, and OBM solutions.
Applications
Thermal Imaging, Semiconductor, Medical
Specification Summary
| Item | Value |
|---|---|
| Material | Silicon |
| Shape | Round |
| Diameter | 5 mm |
| Thickness | Custom |
| Coating | anti-reflective (AR), uncoated, diamond-like carbon (DLC) |
| Transmission bands | LWIR (8-14 μm), MWIR (3-5 μm) |
| MOQ | — |
Full Specifications
| Parameter | Value |
|---|---|
| Type | Silicon wafer |
| Customized Support | OEM, ODM, OBM |
| Weight | 0.003 |
| Parallelsim | < 3 arcmin - 3 arcsec |
| Clear Aperture | ≥90% |
| Flatness | 2 Lambda - Lambda/20 @632.8nm |
FAQ
What are the available sizes for custom orders?
Silicon wafers are available in diameters ranging from 5.0 mm to 800.0 mm.
What is the minimum order quantity (MOQ)?
The minimum order quantity (MOQ) is not specified.
