Custom Size Silicon Spherical Lens, AR Coated

Product description

This spherical aspherical lens made from silicon is designed for applications in thermal imaging, security, and general imaging. With a fixed focal length of either 9.0 mm or 25.0 mm and high efficiency anti-reflective coatings, it ensures over 86% average transmission in the 8-12 μm range. The lens is engineered to perform reliably in demanding environments, supporting temperatures from -40°C to +80°C, making it ideal for various industrial applications.

Key Features

Focal lengths of 9.0 mm and 25.0 mm for versatile application fit.
Average transmission greater than 86% in the 8-12 μm range enhances imaging performance.
IP67 sealing for front lens ensures durability in harsh conditions.
Fixed focus mechanism simplifies integration into systems.
OEM support available for customized solutions.

Applications

Thermal Imaging, Security, Imaging

Specification Summary

Item	Value
Material	Silicon
Shape	Spherical
Focal Length	9 mm
Coating	anti-reflective (AR)

Full Specifications

Parameter	Value
Type	Aspherical Lens
Customized Support	OEM
Warranty	1 year
Logo/Graphic Design	Transfer Sticker
Weight	100g
Average Transmission(8~12Μm)	>86%
Focus Mechanism	Fixed focus
Back Focal Length	11.04mm
Sealing	IP67-Front lens only
External Coating	High Efficiency AR
Operating Temperature	40°C ~ +80°C
Storage Temperature	50°C ~ +80°C
Mechanical Interface	M34 x 0.5

FAQ

What are the available custom sizes?

Custom sizes are available through OEM support, allowing for tailored solutions.

What is the minimum order quantity (MOQ)?

The minimum order quantity is not specified; please contact for details.
