3 mm ZnSe Meniscus Lens, AR Coated
Discover high-quality Zinc Selenide meniscus lenses for thermal imaging and medical applications, with customizable options and low MOQ.
Core attributes
- Material
- ZnSe
- Shape
- Meniscus
- Diameter
- 3 mm
- Surface Quality
- 20/10
- Coating
- anti-reflective (AR)
- Transmission bands
- LWIR (8-14 μm), MWIR (3-5 μm), SWIR (1.7-3 μm), NIR (0.7-1.7 μm), VIS (400-700 nm)
- MOQ
- 1 piece
Product facts
Key attributes
- Material
- ZnSe
- Shape
- Meniscus
- Diameter
- 3 mm
- Surface Quality
- 20/10
- Coating
- anti-reflective (AR)
- Transmission bands
- LWIR (8-14 μm), MWIR (3-5 μm), SWIR (1.7-3 μm), NIR (0.7-1.7 μm), VIS (400-700 nm)
- MOQ
- 1 piece
Product description
Zinc Selenide (ZnSe) meniscus lenses are precision optics designed for applications in thermal imaging, medical devices, and various imaging systems. With exceptional transmittance across multiple bands, including 8-14 μm and 3-5 μm, these lenses are ideal for high-power CO2 laser systems and FLIR applications. The lenses are available in a compact 3.0 mm diameter, ensuring compatibility with various optical setups. Custom manufacturing options are available, allowing for tailored solutions to meet specific project needs.
Key Features
- Surface quality of 20/10 ensures minimal distortion for clear imaging.
- Transmittance range from 600 nm to 21 μm supports diverse applications.
- Clear aperture greater than 90% maximizes light throughput.
- Low minimum order quantity of 1 piece allows for prototyping and small-scale projects.
- Available with AR coatings to enhance performance in specific wavelengths.
Applications
Thermal Imaging, Medical, Imaging
Specification Summary
| Item | Value |
|---|---|
| Material | ZnSe |
| Shape | Meniscus |
| Diameter | 3 mm |
| Surface Quality | 20/10 |
| Coating | anti-reflective (AR) |
| Transmission bands | LWIR (8-14 μm), MWIR (3-5 μm), SWIR (1.7-3 μm), NIR (0.7-1.7 μm), VIS (400-700 nm) |
| MOQ | 1 piece |
Full Specifications
| Parameter | Value |
|---|---|
| Type | Convex Lens, Aspherical Lens, Concave Lens, Achromatic Lens, Plano Convex Lens… |
| Customized Support | OEM, ODM, OBM |
| Warranty | 1 Year |
| Weight | 1 |
| Parallelism | 30 arc sec |
| Clear Aperture | >90% |
| Moq | 1 piece |
| Surface Flatness | 1-2 Lambda (@633nm) |
FAQ
What is the minimum order quantity for these lenses?
The minimum order quantity is 1 piece.
Can these lenses be customized?
Yes, custom manufacturing options, including OEM and ODM support, are available.
