5x1 mm ZnSe Optical Window, AR Coated

Product description

This ZnSe convex window is designed for applications in the 8-14 μm wavelength range, making it ideal for IR imaging and LIDAR systems. Its anti-reflective coating enhances transmittance, ensuring optimal performance in demanding environments. With a range of diameters from 5.0 mm to 400.0 mm and thicknesses from 1.0 mm to 20.0 mm, this window can be tailored to fit specific requirements, providing flexibility for various applications.

Key Features

Wavelength range: 8-14 μm for optimal IR imaging and LIDAR performance.
Customizable sizes from 5.0 mm to 400.0 mm in diameter and 1.0 mm to 20.0 mm in thickness.
Dimension tolerance of ±0.1 mm ensures precise fit for your applications.
Clear aperture greater than 90% for maximum light transmission.
Parallelism of < 3 arcmin for superior optical performance.

Available Sizes

Diameter x Thickness (mm)
202.5 x 10.5
252.5 x 10.5

Specification Summary

Item	Value
Material	ZnSe
Diameter	5 mm
Thickness	1 mm
Coating	anti-reflective (AR)
Transmission bands	LWIR (8-14 μm)
MOQ	—

Full Specifications

Parameter	Value
Type	Optic lens
Customized Support	OEM, ODM, OBM
Warranty	3 Years
Weight	1
Dimension Tolerance	±0.1mm
Clear Aperture	>90%
Parallelism	< 3 arcmin

FAQ

Do you offer custom sizes?

Yes, sizes can be customized from 5.0 mm to 400.0 mm in diameter and 1.0 mm to 20.0 mm in thickness.

What are the tolerances for dimensions?

The dimension tolerance is ±0.1 mm, ensuring precise fitting for various applications.
