2 mm ZnSe Right-angle Optical Prism, AR Coated
Explore ZnSe Micro Right Angle Prisms for CO2 lasers and thermal imaging with custom sizes and high-performance specifications.
Core attributes
- Material
- ZnSe
- Shape
- Right-angle
- Size
- 2 mm
- Thickness
- Custom
- Coating
- anti-reflective (AR), uncoated
- Transmission bands
- LWIR (8-14 μm), MWIR (3-5 μm), SWIR (1.7-3 μm), NIR (0.7-1.7 μm), VIS (400-700 nm)
Product facts
Key attributes
- Material
- ZnSe
- Shape
- Right-angle
- Size
- 2 mm
- Thickness
- Custom
- Coating
- anti-reflective (AR), uncoated
- Transmission bands
- LWIR (8-14 μm), MWIR (3-5 μm), SWIR (1.7-3 μm), NIR (0.7-1.7 μm), VIS (400-700 nm)
Product description
The ZnSe Micro Right Angle Prism is designed for precision applications in the infrared spectrum, particularly for CO2 laser systems and thermal imaging. With its ability to provide 90° beam deviation, this prism is ideal for compact optical assemblies in laser and spectroscopy applications. Its high-purity CVD ZnSe material ensures low absorption across a broad transmission range of 0.6-16 μm, making it suitable for diverse IR applications. Custom sizes are available to fit specific design needs.
Key Features
- Material: High-purity CVD ZnSe ensures low absorption in the 0.6-16 μm range, enhancing performance in IR applications.
- Angle Tolerance: ± 5 arcmin (± 3 arcmin on request) for precise alignment in optical setups.
- Coating Options: Available uncoated or AR-coated for 10.6 μm, providing flexibility for various applications.
- Custom Sizes: Micro dimensions from 2 mm to 5 mm available to meet specific design requirements.
- Surface Quality: 60-40 / 40-20 scratch-dig standard for reliable optical performance.
Applications
Laser, Spectroscopy
Specification Summary
| Item | Value |
|---|---|
| Material | ZnSe |
| Shape | Right-angle |
| Size | 2 mm |
| Thickness | Custom |
| Coating | anti-reflective (AR), uncoated |
| Transmission bands | LWIR (8-14 μm), MWIR (3-5 μm), SWIR (1.7-3 μm), NIR (0.7-1.7 μm), VIS (400-700 nm) |
Full Specifications
| Parameter | Value |
|---|---|
| Prism Type | ZnSe prism |
| Customized Support | OEM, ODM |
FAQ
What is the minimum order quantity (MOQ) for custom sizes?
The MOQ is not specified; please contact for details on custom sizing.
Can I request tighter angle tolerances?
Yes, tighter angle tolerance of ± 3 arcmin is available upon request.
