5 mm ZnSe Right-angle Optical Prism, AR Coated
High-quality ZnSe right-angle prisms with precise angle tolerance and customizable sizes for laser and optical applications.
Core attributes
- Material
- ZnSe
- Shape
- Right-angle
- Size
- 5 mm
- Thickness
- Custom
- Coating
- anti-reflective (AR)
Product facts
Key attributes
- Material
- ZnSe
- Shape
- Right-angle
- Size
- 5 mm
- Thickness
- Custom
- Coating
- anti-reflective (AR)
Product description
Right-angle prisms made from ZnSe are ideal for applications requiring precise beam deviation and high-quality optical performance. With a surface flatness of Lambda/2 at 632.8nm and an angle tolerance of less than 3 arcminutes, these prisms ensure minimal wavefront distortion. Their protective chamfer enhances durability, making them suitable for demanding environments in laser and optical systems.
Key Features
- Surface flatness of Lambda/2 @ 632.8nm ensures wavefront integrity.
- Angle tolerance of < 3 arcmin for precise beam deviation.
- Clear aperture of 90% maximizes light transmission.
- Custom sizes available from 5mm to 200mm for versatile applications.
- OEM, ODM, and OBM support for tailored solutions.
Specification Summary
| Item | Value |
|---|---|
| Material | ZnSe |
| Shape | Right-angle |
| Size | 5 mm |
| Thickness | Custom |
| Coating | anti-reflective (AR) |
Full Specifications
| Parameter | Value |
|---|---|
| Prism Type | Right Angle Prism, Triangular Prism, Dispersive Prisms |
| Customized Support | OEM, ODM, OBM |
| Warranty | 1 month |
| Dimension | 5-200 mm |
| Surface Flatness | Lambda/2 @632.8nm |
| Angle Tolerance | < 3 arcmin |
| Clear Aperture | 90% |
| Chamfer | protective chamfer |
FAQ
What are the available custom sizes for the right-angle prism?
Custom sizes range from 5mm to 200mm.
What is the angle tolerance for this prism?
The angle tolerance is less than 3 arcminutes.
