5x0.5 mm ZnSe Round Optical Window, AR Coated
ZnSe round protective windows for thermal imaging and medical applications, customizable sizes, and high-performance specifications.
Core attributes
- Material
- ZnSe
- Shape
- round
- Diameter range
- 5–500 mm
- Thickness
- 0.5–50 mm
- Coating
- ar
Product facts
Key attributes
- Material
- ZnSe
- Shape
- round
- Diameter range
- 5–500 mm
- Thickness
- 0.5–50 mm
- Coating
- ar
Product description
The ZnSe round protective window is engineered for thermal imaging and medical applications, providing exceptional performance in the 8-14 μm and 400-700 nm bands. With a diameter range of 5.0 to 500.0 mm and thickness options from 0.5 to 50.0 mm, this window ensures high transmittance and minimal IR absorption. Its low scattering damage and thermal shock resistance make it ideal for demanding environments, while AR coatings enhance its functionality in CO2 laser systems.
Key Features
- Diameter range: 5.0 to 500.0 mm for versatile applications.
- Thickness options: 0.5 to 50.0 mm to fit specific requirements.
- Surface flatness: 2λ-λ/8 @632.8nm ensures high optical performance.
- Parallelism: ≤3 arcmin or ≤1 arcsec for precise alignment.
- Customizable support for OEM and ODM projects.
Available Sizes
| Diameter x Thickness (mm) |
|---|
| 252.5 x 25.2 |
Applications
Thermal Imaging, Medical
Specification Summary
| Item | Value |
|---|---|
| Material | ZnSe |
| Shape | Round |
| Diameter | 5 mm |
| Thickness | 0.5 mm |
| Coating | anti-reflective (AR) |
| Transmission bands | LWIR (8-14 μm), VIS (400-700 nm) |
| MOQ | — |
Full Specifications
| Parameter | Value |
|---|---|
| Type | Protective Window |
| Customized Support | OEM, ODM |
| Warranty | 1 Year |
| Weight | 0.05-10 kg(0.11-22.05lb) |
| Dimension Tolerance | ±0.1mm |
| Flatness | 1 Lambda, L/2, L/10 @632.8nm |
| Parallelism | < 3 arcmin or < 1 arcsec |
| Bevel | protetcive bevel |
FAQ
What is the minimum order quantity (MOQ)?
The MOQ is not specified, allowing for potential flexibility in orders.
Can I get custom sizes for the ZnSe windows?
Yes, the product supports custom sizes and OEM/ODM options.
