85 mm ZnSe Spherical Lens, AR Coated
ZnSe spherical lens for 8-14 μm applications, 99% transmittance, customizable, low MOQ of 1 piece.
Core attributes
- Material
- ZnSe
- Shape
- Spherical
- Diameter
- 85 mm
- Transmittance
- 99%
- Coating
- anti-reflective (AR), high-reflective (HR)
- Transmission bands
- LWIR (8-14 μm)
- MOQ
- 1 piece
Product facts
Key attributes
- Material
- ZnSe
- Shape
- Spherical
- Diameter
- 85 mm
- Transmittance
- 99%
- Coating
- anti-reflective (AR), high-reflective (HR)
- Transmission bands
- LWIR (8-14 μm)
- MOQ
- 1 piece
Product description
The ZnSe spherical lens is designed for high-performance applications in the 8-14 μm infrared band, making it ideal for thermal imaging, medical systems, and imaging technologies. With a transmittance of 99%, this lens ensures minimal loss of light, enhancing the efficiency of infrared systems. Its robust construction and high resistance to thermal shock make it suitable for high-power CO2 laser applications. The lens can be customized to meet specific requirements, with a minimum order quantity of just one piece.
Key Features
- Transmittance of 99% for superior light efficiency.
- Spherical shape with a diameter of 85 mm, suitable for various applications.
- AR and HR coatings enhance performance and durability.
- Compatible with high-power CO2 laser systems, supporting up to 200W.
- Custom sizing available with a low MOQ of 1 piece.
Applications
Thermal Imaging, Medical, Imaging
Specification Summary
| Item | Value |
|---|---|
| Material | ZnSe |
| Shape | Spherical |
| Diameter | 85 mm |
| Transmittance | 99% |
| Coating | anti-reflective (AR), high-reflective (HR) |
| Transmission bands | LWIR (8-14 μm) |
| MOQ | 1 piece |
Full Specifications
| Parameter | Value |
|---|---|
| Customized Support | OEM, ODM, OBM |
| Warranty | 3 Years; 3 Year |
| Weight | 0.5kgs |
| Wavelength | 10.6um |
| Edge Thickness | 2mm |
| Transmittance | 99% |
| Moq | 1 piece |
| Structure | Plano-Convex |
FAQ
Is custom sizing available?
Yes, the ZnSe lens can be customized to meet specific requirements.
What is the minimum order quantity?
The minimum order quantity is 1 piece.
