5x0.5 mm ZnSe Step Optical Window, AR Coated

Product description

The Plano Convex Lens made from ZnSe is ideal for applications in infrared imaging and laser systems, providing optimal performance in the mid-infrared range. With a diameter of 5.0 mm and thickness options from 0.5 mm to 40.0 mm, this lens features anti-reflective coatings that enhance transmittance. The lens is designed to meet high standards of flatness and clear aperture, ensuring reliable optical performance for demanding applications.

Key Features

Diameter of 5.0 mm ensures compatibility with compact optical systems.
Thickness options from 0.5 mm to 40.0 mm allow for versatile application fit.
Flatness of 1/10 lambda provides superior optical quality.
Clear aperture greater than 85% of diameter maximizes light transmission.
Chamfered edges (0.25 mm x 45 degrees) enhance handling and installation.

Available Sizes

Diameter x Thickness (mm)
5 x 20.2

Specification Summary

Item	Value
Material	ZnSe
Shape	Step
Diameter	5 mm
Thickness	0.5 mm
Coating	anti-reflective (AR)
MOQ	—

Full Specifications

Parameter	Value
Type	Plano Convex Lens
Weight	0.1
Flatness	1/10 lambda
Chamfer	0.25mmx45degree
Clear Aperture	>85% of diameter

FAQ

Is custom sizing available?

Variant sizes available include 5.0 mm diameter with thickness options up to 40.0 mm.

What is the minimum order quantity?

Minimum order quantity details are not specified; please inquire for specific requirements.
